INFORMATION DETAILS
ID: 13355087
|
Year: 2015
|
Make: Skyjack
|
Model: SJ6832 RTE
|
Type: New
|
| MSRP:
N/A |
Engine Size - cc: N/A |
| Work Height: | 38' (11.58 m) |
| Raised Platform Height: | 32' (9.75 m) |
| Lowered Platform Height: | 54'' (1.37 m) |
| Overall Width: | 69.5'' (1.76 m) |
| Overall Length: | 107'' (2.72 m) |
| Platform Width (Inside Dimension): | 56'' (1.42 m) |
| Weight: | 7,885 lbs (3,577 kg) |
| Turning Radius (Inside): | 60'' (1.52 m) |
| Turning Radius (Outside): | 156'' (3.96 m) |
| Lift Time (With Rated Load): | 39 sec |
| Maximum # of Persons: | 4 |
| Tire Type: | Foam Filled Non-Marking |
| Tire Size: | 26 x 12 |
SELLER DESCRIPTION
|
|
|
STANDARD FEATURES
|
-
Crossover symmetrical 4WD
-
Drivable at full height with roll out deck fully extended
-
5’ roll out extension deck
-
16hp AC electric motor with motor controller
-
48V 250Ah battery pack
-
Low voltage battery protection
-
Multiple wet disc spring applied, hydraulic release (SAHR) brakes
-
110V AC outlet on platform with GFI
-
45% Gradeability
-
Standard foam filled grip lug non-marking tires
-
Tilt alarm with drive & lift cut-out
-
Lanyard attachment points
-
All motion audible alarm
-
Operator horn
-
Hinged railing system
-
Forklift pockets and tie down/lift lugs
-
Full height spring-hinged gate at rear of unit
-
Relay based control system
-
Color coded and numbered wiring
-
Telematics ready
|
